Which Ruud air handler goes with a Ruud Ultra heat pump?

Usually the RHMVY. It has a constant CFM motor that ramps from low to full airflow with the EcoNet Smart Thermostat.

Who makes Ruud air handlers?

Rheem. Rheem Sales Company manufactures Ruud's residential heating and cooling products.

Does a Ruud air handler need registration for the warranty?

Yes. Ruud's 10-year parts coverage requires registration.

Can you replace just the air handler and keep my outdoor unit?

Sometimes. It depends on the refrigerant and whether a matched Ruud air handler exists for that outdoor model; we check before quoting.

Do you service older Ruud air handlers?

Yes. We repair Ruud air handlers of any age and stock the common parts.

Ruud Air Handlers Long Island | Installation and Service

Air Handler Brand

About Ruud Air Handlers

Domino Fuel is a Ruud Pro Partner contractor. We install, repair and replace Ruud air handlers in Long Island attics, basements and closets, and our factory-trained technicians answer no-cool and no-heat calls 24/7.

Ruud dates back to Edwin Ruud's water heaters of the 1880s and has belonged to Rheem since 1959. Rheem Sales Company manufactures Ruud's heating and cooling products, so Ruud air handlers come out of the same engineering as Rheem's.

Ruud's air handlers are the indoor partner for its outdoor units. On the RH2VY and RHMVY, the indoor coil is aluminum fins on grooved aluminum tube, the steel cabinet has 1 inch of foil-faced insulation, and leakage is under 2% at 1 inch of water column per ASHRAE Standard 19. A built-in A2L sensor and mitigation board pauses the outdoor unit if it detects excess refrigerant.

Ruud lists these air handlers as part of its Endeavor Line.

Get a Free Quote Today Call (631) 779-3196

All Models Serviced

Model Lineup

Ruud Air Handler Models We Install and Service

Ruud's own catalog lists these families. Ruud doesn't give its air handlers Ultra or Achiever names, so the right column shows which outdoor series each one usually pairs with.

Ruud Model Family	Sizes and Widths	Highlights	Usual Outdoor Match
RHMVY	24,000 to 60,000 Btu/h; 17.5, 21 or 24.5 in wide	Constant CFM motor that ramps from low to 100% with EcoNet	Ultra UP19AY and RD18AY
RH2VY	24,000 to 60,000 Btu/h; 17.5 to 24.5 in wide	Two-stage plus variable airflow, Bluetooth commissioning	Ultra and Achiever Plus
RH2TY / WH2TY	24,000 to 60,000 Btu/h	4-way convertible, aluminum coil, heater kit ready	Achiever Plus and Achiever two-stage units
RF1PY / RF2TY	Per model	Front or bottom return for closets	Achiever and Choice
RB2TY / WB2TY	Per model	Two-stage, 35 inches tall	Low attics with any series
WH1AY / RH1AY	24,000 to 60,000 Btu/h	Compact 4-way design for tight spaces	Choice and basic replacements

Long Island Homes

Ruud Air Handlers for Long Island Homes

The usual Long Island setup is an oil-fired boiler for heat and a central air system on top, with the air handler tucked in the attic. Summer attic heat on the Island is brutal on drain lines and duct joints. Ruud's low-leak cabinets help, but what really protects your ceiling is a secondary drain pan and a float switch, and we install both.

Heat pump conversions change the job. The air handler now carries winter heat, so we size the field-installed heater kit for backup on the coldest nights and set the blower to match the outdoor unit. With an EcoNet Smart Thermostat, the RHMVY ramps gradually from low to full airflow; on a standard 24V two-stage thermostat it runs at two speeds.

Basements and utility rooms are easier, and the 4-way convertible cabinets on the RH2TY and WH1AY let us set the unit upflow, downflow or on its side to fit the existing ducts.

Warranty

Ruud Air Handler Warranty

Ruud's RH2VY, RH2TY and WH1AY pages each list a limited warranty of 10 years on conditional parts, with registration required. On the RHMVY, Ruud words it as Parts: 10 Years, and registration is still required. Full terms come with the Ruud warranty certificate, so keep it with your closing papers; we register the unit for you after the install.

On top of the manufacturer's coverage, Domino backs every installation with a 1-year labor warranty.

Compare Brands

Ruud vs Rheem Air Handlers

Ruud and Rheem air handlers are built by the same company, and their catalogs share the same family codes, RHMVY, RH2VY, RH2TY and the rest. Specs and warranty language match.

Pick the brand that matches your outdoor unit. A Ruud Ultra or Achiever condenser should go with a Ruud air handler so the AHRI rating and warranty paperwork stay under one name. If you're leaning Rheem, our Rheem air handler page shows that lineup.

Repair & Service

Ruud Air Handler Repair and Service

Our technicians carry blower motors, capacitors, transformers, float switches and condensate pumps for Ruud units. A spring visit cleans the coil and drain and checks heat strips before they're needed.

Ceiling stain under the attic unit: a plugged drain line or a rusted secondary pan.
Air handler runs but rooms stay warm: a frozen coil from a dirty filter, or low refrigerant.
Blower won't start at all: a blown fuse on the control board, a bad transformer, or a failed motor.
Outdoor unit off and indoor unit running alone: the refrigerant sensor has paused the system after detecting a leak.
Loud whistle from the cabinet: a missing panel seal or a filter rack that isn't closed.

Installation

Ruud Air Handler Installation and Replacement

When we install a Ruud air handler, often during an AC installation and replacement, the job runs in this order:

Call for a quote. The main cost drivers are how hard the unit is to reach, any duct changes, the heater kit, which Ruud family you pick, and whether we're swapping the condenser on the same day.

Check the Ruud outdoor unit's series and size and choose the matched air handler.
Measure the space and pick a family and airflow direction that fits it.
Take out the old air handler, set the Ruud unit on a secondary pan, and reconnect supply and return ducts with sealed joints.
Install the heater kit if needed, then the drain lines and float switch.
Braze, vacuum and charge with the outdoor unit, then set blower speeds and test both modes.
